| Material : |
- Made of woven high density black polyethylene (HDPE) fibers, warp x weft, laminated on both sides with low density polyethylene (LDPE) coating.With reinforced rims by heat sealing on all sides. (or 2 sides heat sealing and 2 sides double stitching). and a 5 mm diameter polyethylene (PE) or polypropylene (PP) rope on the edge. inside the hem. 1000 denier minimum.
|
| Material Weight : |
- Minimum 190 g/m2(+- 20 g/m2).
|
| Tensile Strength : |
- Minimum 600 N both directions of warp and weft (BS 2576, 50 mm grab test or equivalent)
|
| Tear Strength of the eyeist : |
- Minimum 700 N inside the eyetests as per ISO 1421-1,pulling lengthwise with a hook of 8mm wire diameter to test in 2 eyetests in each side.
|
| Tear Strength : |
- Minimum 100 N both directions (BS 4303 wing tear or equivalent) or under ISO 4674 (A2).
|
| UV Resistance : |
- Stabilized against ultraviolet rays and excess heat for long outdoor exposure. Maximum 5% loss of original tensile strength under ISO 1421 after 1500 hours ultraviolet (UV) under ASTM G53 / 94 (UVB 313 nm peak).
|
| Welding : |
- Only one is allowed along the middle of the sheet, length wise. Minimum resistance is 80% of the original tarpaulin tensile strength in the weft under ISO 1421 plus additional procedure.
|
| Reinforcement Eyelets : |
- Provided with aluminum eyelets or equivalent on four sheet sides of the single sheets at 100 cm (+- 5 cm) centre to centre, providing very strong xation points.
|
| Colour : |
- White sun reflactive on both sides. Inner black bars to ensure opacity.
|
| Packing : |
- Plastic tarpaullin sheets are packed in bales.It is ideals to pack 5 pieces of product per bale and to secure it with polyester straps.However different packing methods may be accepted in order to maximize icadability in pallets and containers.
|
| Optimal Shipping / Container Information : |
- 3,300 pieces/sheets per 20'DC (without pallets)
- 6,500 pieces/sheets per 50'DC (without pallets)
- 6,500 pieces/sheets per 50'HC (without pallets)
- 2,800 pieces/sheets per 20'DC (without pallets)
- 6,000 pieces/sheets per 40'DC (without pallets)
- 6,000 pieces/sheets per 40'HC (without pallets)
|
| Pallet Details : |
- Dimensions (WxLxH) 780x1120x144 mm. Maximum height of the packed pallet : 115 cm. pallets should be shrink-wrapped and strapped the palletized goods must not exceed the length and width of the pallet.
|
| Manufacturer Marking : |
- Every tarpaullin sheet 4x5 m should include a tag stitched in hem. with the manufacturer identification (letters not higher than 2.5 cm.)The tag should include the manufacturer's name,unique reference batch number and the date of manufacturing .No company logo should be included with the manufacturer's marking.
|
| Expected life Span: |
- It is expected that Reinforced plastic tarpaulin will maintain sheltering and waterproof capacities for one year under the strongest weather conditions.
|
| Reference Information : |
- For additional information about the use of this product see : http://www.plastic-sheeting.org
http://www.sheltercentre.org/library
|
| Printing of UNHCR logo : |
- CR logos must be printed on both sides of the sheet , the 6A line of five UNH logo is cut-across the five meter side,placed one meter from the bottom edge of the five-meter side.
For UNHCR visibility logo printing purpose details see the Reinforced plastic arpaulin graphic and the UNHCR logo .Application reference available on the next page,where size of logo is 45 cm wide and 55 cm height.
Alternativels the number of logos on the line may be reduced to 4, with a proportional increment on the size of the logo to 50cm widex60 cm height.
|
| Typeface (font), |
Helvetica Bold |
| Colour specification for printing : |
Pantone Blue 300 or quadrichrome (CMyK), C=100%, M=45%, Y=0% , K=0% |
